Accsoon Cineview Master 4K Receiver - Wireless Video Receiver (RX)
Accsoon CineView Master 4K Receiver
The Accsoon CineView Master 4K Receiver is the receiving unit for the CineView Master 4K wireless video system, designed for demanding on-set monitoring and live production workflows. It delivers true 4K 60 fps transmission with tri-band wireless operation across 2.4 GHz, 5 GHz, and 6 GHz, plus DFS support for reliable performance in busy environments.
Built for speed and stability, this receiver offers ultra-low latency, long-distance signal reception, and the ability to monitor across multiple devices. It also supports simultaneous SDI and HDMI output, while the Accsoon SEE app adds flexible remote viewing and control options.
Designed for Professional Production
Powered by an 8K high-performance A/V processor, the CineView Master 4K Receiver is engineered to handle demanding video signals with ease. Its aerospace-grade aluminum alloy body combines durability with a lightweight form factor, and the integrated 1.05-inch full-color LCD screen provides clear status information at a glance.
The receiver can be powered via DC input or compatible NP-F batteries, making it easy to integrate into a wide range of production setups. Quiet heat dissipation helps keep operation unobtrusive during shoots.
Key Features
- Receiver unit for the Accsoon CineView Master 4K system
- True 4K 60 fps wireless video transmission
- Tri-band wireless support: 2.4 GHz, 5 GHz, and 6 GHz
- DFS wireless transmission for improved reliability
- Low latency: under 25 ms at 1080p, under 35 ms at 4K
- Long-range transmission up to 2.5 km in ideal conditions
- Supports monitoring on up to 5 devices
- Simultaneous HDMI and SDI output
- Compatible with the Accsoon SEE app
- 8K high-performance A/V processor
- Powered by DC input or NP-F550 / NP-F750 / NP-F970 batteries
- Compatible with Accsoon V-Mount battery adapter
- 1.05-inch full-color LCD display
Specifications
- Protocol: Accsoon RTMS 4.0 proprietary protocol
- Video output: HDMI, 3G SDI
- SDI output formats: 1080p 24/25/30/50/60p Level A; 1080i 50/60i
- HDMI output formats: 4K 24/25/30/50/60p; 1080p 24/25/30/50/60p; 1080i 50/60i
- HDMI loop-out: Matches HDMI video input
- DC input: 5.5 mm x 2.1 mm, center positive
- DC voltage: 7.4–16.8 V
- Average power consumption: 5.0 W
- Audio: Embedded HDMI and SDI
- Operating temperature: -10°C to 40°C
- Dimensions without antennas: 130 x 95 x 32 mm
- Weight without antennas: 320 g
Package Contents
- 1x Accsoon CineView Master 4K Receiver
