Feelworld 5.5'' S55 V3 1920x1152 4K HDMI DC Out 3D Lut Field

Feelworld 5.5" 4K S55 V3 HDMI 3D LUT Field Monitor: An asset to Videographers

The Feelworld 5.5" 4K S55 V3 HDMI 3D LUT Field Monitor is an exceptionally compact and lightweight video asset, fitted with an FHD IPS screen that provides sharp image display, perfect for precise details. The device presents a versatile solution for video professionals.

The intuitively designed control panel makes the monitor easy to operate, making it ideal for use on gimbals. With its support for 3D LUTs, film looks can be previewed on the monitor. Accurate waveform analysis saves costs, and the monitor provides multiple power supply options for extended shooting periods. The addition of a stereo headphone output and 8.4V DC output for DSLR or system cameras turns this monitor into a comprehensive tool for filmmakers.

Main Features of the Feelworld 5.5" 4K S55 V3 HDMI 3D LUT Field Monitor

• 5.5-inch FHD IPS screen
• Lightweight design
• User-friendly controls
• Support for 3D LUTs
• 16.7M color screen (8 bit)
• 70% NTSC color gamut
• 1920x1080 pixel resolution
• Dot pitch: 0.069 (H) X 0.069 (W) mm
• 16:9 Aspect ratio
• 450 cd/m² brightness
• 1000:1 contrast
• LED backlight
• Viewing angle: 80°/80°(L/R) 80°/80°(U/D)
• HDMI support format: 4801/5761/480p/5T6p 10801 (60/59.94/50) 720p (60/59.94/50/30/29/25/24/23.98) 1080p (60/59,94/50/30/29,97/25/24/245F/23,98/23 9856) 4K UHD 3840 2160p (30/29,97/25/24/23,98H2), 4096 x 2160p (24Hz)

Additional Specifications

• Power consumption: <8W
• Input voltage: 7~24v
• Battery plate: F9T0/ LP-£6 Dual-purpose battery plate
• Operating temperature: 20°C - 50°C
• Storage temperature: 30°C - 60°C
• Mounting method: 4-20 threaded points (bottom, right)
• Dimensions: 151 x 92 x 29.5 mm
• Weight: 190 grams

Box Contents

• 1x Feelworld 5.5" 4K S55 V3 HDMI 3D LUT Field Monitor
• 1x Sunshade
• 1x Tilt arm
• 1x Micro HDMI cable
• 1x Type-C to USB cable
